82210/225 82210/260
Table dimensions Ø 225 mm Ø 260 mm
Plate height (Horizontal position) 340,5 mm 333 mm
Center height (Vertical position) 210 mm
Central bore Ø 52 H7
Working position 0º / 5º / -20º
Faceplate "T" slot width Central 14H7
Rest 14H12
Indexing accuracy with direct encoder RON 285C ± 25 seconds
Clamping system Hydraulic
Clamping torque rotation 660 Nm
Clamping torque tilting 1.650 Nm
Clamping hydraulic pressure 80 BAR
Load capacity - Vertical axe (Plate horizontal) 100 Kg
Load capacity - Horizontal axe (Plate vertical) 50 Kg
Nominal torque 1.200 Nm
Recommended engine 8 Nm / 700 rpm
Total reduction 180/1
Flatness of plate turning 0,025 mm
Perpendicularity of plate turning 0,020 mm
Concentricity center bore 0,015 mm
Weight (without engine) 400 Kg 425 Kg
Data sheet 82210.225 Data sheet 82210.260
